Filtering

Filter bar

Add a filter-bar panel when a page has several filter controls and you want them pinned together in one row instead of scattered across the layout.

FiltersRegion Last 30 daysSegment

What you can do

A filter-bar panel groups filter panels into one horizontal bar above the charts.
spec.panels is an ordered list of filter panel ids, up to 24; spec.title is optional.
Each grouped filter panel keeps its own spec: control, param, and targets.
showOnPages on a filter panel controls which pages it appears on; the filter-bar panel arranges panels already declared elsewhere on the page.

filter-bar is a layout panel; it contains filter panels and does not itself read or write data.

Spec

View spec

[
  {
    "id": "region",
    "type": "filter",
    "title": "Region",
    "data": {
      "query": "SELECT DISTINCT region FROM orders ORDER BY 1"
    },
    "spec": {
      "control": "select",
      "valueField": "region",
      "param": "region"
    }
  },
  {
    "id": "dates",
    "type": "filter",
    "title": "Dates",
    "data": {
      "query": "SELECT DISTINCT order_date FROM orders ORDER BY 1"
    },
    "spec": {
      "control": "date-range",
      "valueField": "order_date",
      "loParam": "order_date_lo",
      "hiParam": "order_date_hi",
      "presets": [
        "last-30d",
        "qtd",
        "ytd"
      ]
    }
  },
  {
    "id": "controls",
    "type": "filter-bar",
    "title": "Controls",
    "spec": {
      "title": "Filters",
      "panels": [
        "region",
        "dates"
      ]
    }
  }
]

The controls filter-bar panel groups the region and dates filter panels into one row; each filter panel keeps its own control and param.

Try it live

Open the interactive-filters template in the Builder

Open interactive-filters to see fv2-filter-bar pin four filter panels in one row: the region control, a quota toggle, a minimum-revenue number, and a rep search.
